Pump Type
|
Drip type infusion pump
|
Pumping Way
|
Peristalic fingers
|
Adjustable Drop Rate Range
|
1-266 drop/min (step: 1 drop/min)
|
Adjustable Volume Rate Range
|
1~1200 ml/h (when 1~99.9 ml/h, step: 0.1 ml/h; greater than 99.9 ml/h, step: 1 ml/h)
|
Flow Precision
|
Within 3% more or less(using the IV set appointed by the manufacturer or calibrated high quality IV set)
|
Mechanical precision
|
within 2% more or less
|
Purge Rate
|
800 ml/h
|
KVO Rate
|
1 ml/h (1~300 ml/h)
3 ml/h (greater than 300 ml/h)
|
Infusion Volume Range
|
1 ml~9999.9 ml (step: 0.1 ml)
|
Maximum Accumulated Volume
|
9999.9 ml (step: 0.1 ml)
|
Time Range
|
1 min~9999 min (step: 1 min)
|
Occlusion Alarm Threshold
|
High: 800 mmHg+-200 mmHg (106.7kPa+-26.7kPa)
Medium: 500 mmHg+-100 mmHg (66.7kPa+-13.3kPa)
Low: 300 mmHg+-100 mmHg (40.7kPa+-13.3kPa)
|
Alarm
|
Infusion Complete, Empty, Faulty Signal, Misoperation, Occlusion, Door Open, Air Bubble, Low Battery, Setting Error, AC power off, Idle.
|
Air Bubble Detector Method
|
ultrasonic wave, sensitivity: more than or equal
25 μL
|
Fuse
|
F1AL/250V ("F" indicate fast,"L" indicate low breaking capacity), 2 pcs (installed inside pump).
|
Internal Battery
|
11.1V rechargeable li-ion battery. Capacity:more than or equal 2000mAh;
the pump can work more than 4 hours at the flow rate of 25 ml/h after charging for 8 hours (Medium rate specified by GB 9706.27-2005).
|
Power
|
less than or equal 40VA
|
Size
|
140*157*220mm
|
Weight
|
1.8KG
|
Environment Requirements
|
Transport
Ambient Temperature: -30°C~+55°C
Relative Humidity: 20%~95% (non-condensing)
Atmosphere Pressure: 70kPa~106kPa
Storage
Ambient Temperature: -30°C~+55°C
Relative Humidity: 20%~95%
Atmosphere Pressure: 70kPa~106kPa
Operation
Ambient Temperature: +5~+40°C
Relative Humidity: 20%~90%
Atmosphere Pressure: 86kPa~106kPas
|
Calibration function
|
disposable IV set of any brand is suitable for this pump
|
Three working modes
|
Rate/Volumn
|
Alarm
|
Infusion Complete, Empty, Faulty Signal, Misoperation, Occlusion, Door Open, Air Bubble, Low Battery, Setting Error, AC power off, Idle.
|
